DTM Primer Sealer 4:1

Multifunctional acrylic primer

Variants

Colour Art. No. Capacity Quantity per carton
grey14214 0,8 l + 0,2 l6
white14212 0,8 l + 0,2 l6
black 14213 0,8 l + 0,2 l6
grey fast15193 0,8 l + 0,2 l6
white fast15191 0,8 l + 0,2 l6
black fast15192 0,8 l + 0,2 l6
grey slow14984 0,8 l + 0,2 l6
white slow 14982 0,8 l + 0,2 l6
black slow14983 0,8 l + 0,2 l6
black131563,6 l4
grey117213,6 l4
white144603,6 l4
hardener117220,9 l4
hardener slow149810,9 l4
hardener fast151900,9 l4

Gloss grade

matt
DTM Primer Sealer 4:1

Technical documentation

Weight/Volume Calculator

mlg
Primer
Hardener:00
Total of mixture00
Minimum thinner0%00
Total of mixture00
Maximum thinner0%00
Total of mixture00
Thinner value %00
Warning: Value is not within the tolerance given by the manufacturer. (Min: , Max: ).
Total of mixture00

Video

Description

High-quality multifunctional 2-component acrylic primer with anti-corrosion additives. Thanks to the use of advanced technology and high-class ingredients, the product has a very wide range of applications. It works perfectly both as a filling undercoat and an insulating primer. It can be applied directly to metal, providing excellent anticorrosion protection for areas sanded to bare steel. It insulates difficult substrates and body fillers very well from varnish coatings, protecting them against the so-called mapping effect. An additional advantage of the primer is the possibility of applying it “wet on wet”, no sanding required.

Mixing the 3 colors of primer available in the right proportions allows you to obtain 2 additional colors, making it possible to work in the full spectrum of the grey system and select the recommended color of primer for the target base coat color.

Advantages

  • Excellent anti-corrosion protection of steel
  • Strong adhesion to various types of surfaces
  • Very good insulating and filling properties
  • Very short curing time
  • Can be applied using the “wet on wet” technique
  • Working in the spectral gray system.

Substrates

Mutifunctional acrylic primer DTM PRIMER SEALER can be applied directly on:

  • Steel and aluminum after matting and degreasing.
  • Zinc-coated steel and galvanized steel after matting and degreasing.
  • Sanded glass fibre-polyester laminates (GFK/GRP).
  • Polyester body fillers and putties.
  • Epoxy primers.
  • Wash primers.
  • Old paint coatings in good condition after matting and degreasing.

Good surface preparation is essential to achieve the best repair results.

Important informations

  • Przetrzeć odtłuścić

    degrease

  • Proporcje mieszania

    Mixing proportions
    4 : 1 + 5 ÷ 10%

  • Lepkość natryskowa

    Spraying viscosity
    30 ÷ 40s / 20°C

  • Żywotność mieszanki

    Pot life for the mixture
    15 min / 20°C

  • Liczba warstw

    1÷2 layers
    HVLP / RP
    ø1,6 ÷ 2,0 mm

  • Czas odparowania

    between layers
    ok. 5 min.

  • Czas odparowania

    before baking
    ~ 10 min.

  • Czas utwardzania

    Drying time
    2 ÷ 3 h / 20°C
    20-30 min. / 60°C

  • Szlifowanie na sucho

    P360 ÷ P500

  • Szlifowanie na mokro

    P600 ÷ P1000

Application process

  • Zastosowanie
  • Use

    For car repairs. As a sanding primer (in the filling or isolating version) and for the application wet on wet.

  • Proporcje mieszania
  • Mixing proportion by volume

    Primer: 4
    Hardener: 1
    Thinner:

    • 5-10% for filling version
    • 15- 20% for isolating version
    • 25-30% for wet on wet

    Stir thoroughly until obtaining a homogenous mixture.

  • Lepkość natryskowa Mieszanie wg wagi
  • Mixing proportion by weight

    Primer: 100
    Hardener: 17,4

    Stir thoroughly until obtaining a homogenous mixture.

  • Lepkość natryskowa
  • Spraying viscosity
    • 40÷30 seconds at 20°C as a filling primer (thinner 5-10%)
    • 25÷20 seconds at 20°C as an isolating primer (thinner 15-20%)
    • 19÷17 seconds at 20°C as wet on wet (thinner 25-30%)
  • Żywotność mieszanki
  • Pot life for the mixture

    About 15 minutes at 20°C for filling and isolating versions
    About 20 minutes at 20°C for wet on wet.

  • Liczba warstw
  • Number of layers

    Sanding version:
    1÷2 layers
    Filling primer – approx. 80 µm for each dry layer.
    Isolating primer – ok. 50 µm for each dry layer.

    RP gun parameters
    Nozzle: 1,6÷2,0 mm; Pressue: 2,0÷2,2 bar.
    HVLP gun parameters
    Nozzle: 1,5÷1,7 mm; Inlet pressure: 2,0 bar.

    Wet on wet version:
    1,5 layers
    approx. 30µm for each dry layer.
    RP gun parameters
    Nozzle: 1,2÷1,4 mm; Pressure: 2,0-2,2 bar.
    HVLP gun parameters
    Nozzle: 1,3÷1,5 mm; Inlet pressure: 2,0 bar.

  • Czas odparowania
  • Flash off time
    • Between layers: 5-10 minutes
    • Before applying solvent basecoat system: about 20 minutes
    • Before applying waterborne basecoat system: about 30 minutes

    Flash off time depends on the temperature and coating thickness.

  • Czas utwardzania
  • Drying time

    Drying time at 20°C:

    • Isolating primer /50÷100 µm/ready for sanding after 1,5÷2,5 h.
    • Filling primer /80÷160 µm/ready for sanding after 2÷3 h.

    Baking time for panel temperature of 60°C:

    • Isolating primer /50÷100 µm/ ready for sanding after baking for 15÷20 minutes and surface cooling (about 1h).
    • Filling primer /80÷160 µm/ ready for sanding after baking for 20÷30 minutes and surface cooling (about 1h).

    Temperatures below 20°C significantly increase the drying time.

  • Suszenie promieniem IR
  • IR drying

    Isolating primer /50÷-100 µm/: 6÷8 minutes under short wave.
    Filling primer /80÷160 µm/: 8÷10 minutes under short wave.
    Do not exceed maximum temperature of 60°C.
    Use according to the recommendations of the equipment manufacturer.
    Wait about 10 minutes before starting IR drying.

  • Szlifowanie na mokro
  • Wet sanding

    Machine sanding: P600÷P1000
    Manual sanding: P800÷P1000.

    Wet on wet version does not require sanding!

  • Szlifowanie na sucho
  • Dry sanding

    Machine sanding: P360÷P500.
    Manual sanding: P320÷P500.

    Wet on wet version does not require sanding!

  • Informacja
  • Further work

    2K acrylic primers can be directly over coated with:

    • 2K top coats.
    • 1K base coats.

    And also:

    • 2K polyester body filler and putties.
    • 2K acrylic primers
  • Informacja
  • General notes
    • Do not exceed recommended doses of the hardener!
    • The best repair results can be achieved by painting at room temperature. The temperature in the body shop and the temperature of the product should be similar. When working with 2K products, it is recommended to use personal protection equipment. Protect the eyes and airways.
    • The rooms should be well ventilated.
    • Clean the guns and equipment immediately after use.

    Caution: To maintain safety, always follow the instructions given in the MSDS for the products.
